TOPPING PA5 Fully Balanced Class D Power Amplifier - High-Performance Audio Amp for Home Theater, Studio & Hi-Fi Systems

Product Description

Features:-

>Fully Balanced Class D amplifier architecture.

>Dual TRS input options.

>Clean and Powerful output.

>Ultra-low distortion ratings.

>High Signal-to-Noise Ratio.

Technical Parameters:-

>Output Power(THD+N 10%): 140Wx2.

>Output Power(THD+N 1%): 125Wx2.

>SNR: 124dB.

>THD+N: <0.0004%.

Topping PA5 is a brand new fully balanced Class D power amplifier designed specifically to power our HiFi speaker systems. It has a newly-developed Class D amplification circuit that produces quality signal amplification with ultra-low distortion, clean background, and powerful thrust. PA5 is capable of providing up to 140Wx2 output at 4Ω of load(THD+N 10%). Upgrade your desktop speakers with the fully balanced PA5 class D power amplifier.

Fully Balanced Class D Amplifier:-

PA5 features Topping's newly developed Class D power amplifier circuit that delivers outstanding signal amplification with ultra-low distortion and high SNR values. PA5 is an ideal power amplifier as it maintains the true high-resolution clarity of the sound signal and makes it ready for powerful HiFi speakers.

Ultra-Low Distortion & High SNR Ratings:-

Topping PA5's professional design enables it to achieve ultra-low THD+N distortion as well as high SNR(signal-to-noise ratio) ratings. The device has <0.0003% THD+N ratings at 8Ω of load. It also achieves 124dB SNR ratings. Both of these reflect the quality performance that PA5 holds within it. If you are looking for a powerful power AMP for your stereo speakers, PA5 will serve you well with its true high-resolution performance.

Powerful Output For Your HiFi Speaker System:-

Not only the Topping PA5 maintain clarity and resolution for the sound signal, but its main purpose is also to provide powerful sound signal amplification. it excels at that with a powerful output thrust of 140W@4Ω load(THD+N 10%). Even at high quality 1% THD+N, the PA5 provides up to 125W@4Ω of load. It can power your stereo speakers with ease.

Designed To Use With Topping's Latest Lineup:-

Topping Recently launched two new Balanced desktop DAC's, the D10 Bal and the E50. The latest PA5 is designed to use with them with its dual TRS balanced input ports. Users can switch between the two inputs via the toggle switch available at the front.
